DC250V~DC1000V IP20 IP54 Integrated Generator Systems

Basic Information
Place of Origin: China
Brand Name: ANE
Model Number: TISP030NL1K
Minimum Order Quantity: 1
Packaging Details: wooden box
Delivery Time: 30 work days
Payment Terms: T/T, L/C
Supply Ability: 50 per month
Name: DC250V~DC1000V IP20/IP54 Integrated Generator Systems Port Voltage Range: DC200V~DC950V
Constant Power Voltage Range: DC250V~DC1000V AC Side On Grid Rated Power: 30kW
AC Side On Grid Rated Voltage: AC380V/AV400V/AC415V(Optional) Voltage Range: AC400V±20%
Rated Frequency: 50Hz/60Hz(Optional) Frequency Range: 45Hz~55Hz/55Hz~65Hz
Current Harmonics: <=3% Max. Current: ±45A
Power Factors: ±1 Feed Current: <=0.5%
AC Side Off Grid Rated Frequency: 50Hz/60Hz(Optional) Unbalanced Three Phase Load Capacity: 100%
System Max. Efficiency: >=96% Overload Capacity: 1.1 Times 10 Min; 1.2 Times 1 Min
Display: LCD Touching Screen (8") Storage Temperature: -40°C~75°C
Working Humidity: <=95%RH, No Condensation Altitude: <=3000m
Noise Level: <=65dB Communication Interface: Ethernet, 4G
Service Life: More Than 10 Years Installing: Pedestal Installing
Cooling: Forced Air Cooling With Intelligent Speed Adjustment Wright: <=400kG
Size: 600mm*800mm*1800mm(indoor); 900mm*805mm*2050mm(outdoor)
High Light:

IP54 Integrated Generator Systems

,

DC250V Integrated Generator Systems

,

Pedestal Installing Integrated Generator Systems

DC250V~DC1000V IP20/IP54 Integrated Generator Systems



Product Introduction



The integrated photovoltaic generator systems, diesel generators, and the energy storage device integrated with, DC and AC can be converted in practical applications, diesel generators can be connected in parallel operation and, having adjustable dynamic operating mode, and seamless network a plurality of functions and systems, and photovoltaic MPPT tracking and resynchronize the virtual machine, and further comprising interactive data management system, widely used in areas without power, emergency power generation and power supply in the scene.



Features

DC250V~DC1000V IP20 IP54 Integrated Generator Systems 0

DC250V~DC1000V IP20 IP54 Integrated Generator Systems 1
